General info | |
---|---|
Year | 1998 |
Flag | Italian |
Builder | Cantieri Tommasi - Ancona - Italy |
Class society | RINA |
Class notation | 100 A.1.1. - Nav IL; salvage tug; oil recovery ship - flash point >60C; FFQ-1; IAQ-1;TPF(kN) 608 |
IMO number | 9186572 | Main particulars |
Length OA | 33,90 mt |
Length BPP | 31,82 mt |
Breadth moulded | 10,80 mt |
Depth moulded | 5,60 mt |
Gross tonnage | 478 T |
Net tonnage | 144 T |
Maximum draft | 4,90 mt | Cargo capacities |
Working Clear Deck - space | 77 sqm |
Working Clear Deck - length x breadth | 11,50mt x 6,70mt |
Fuel Oil | 273 cbm |
Fresh Water | 90 cbm | Machinery/Propulsion |
Bollard pull max | 62 T |
Main Engines | 2 x MAN 8L 28/32 - 1.960kW each @ 775rpm |
Drive type (Direct/Diesel Electric) | Direct |
Total power (BHP) | 5.300 |
Bow thruster(s) (number and BHP) | Ulstein 45 TV x 400 BP |
Diesel generator | 2 x Volvo 300 kW |
Harbour generator | 1 x Volvo 106 kW |
Emergency generator | 1 x Volvo 106 kW |
Fuel type - (MGO / IFO / HFO) | MGO | Anchor handling capacities |
Winch Type - Double/Triple Drum | Hatlapa hydraulic 600kN - Double Drum |
Winch - Pull Rating | 1st line pull 650 kN - 0/8 mt/min - T |
Winch - Brake Rating | 1350 kN - T |
Towing Drum wire capacity | steel wire 600mt x 48mm diam |
Spare tow wire - length / diameter | 600mt x 48mm diam |
Tugger Winch (number / capacity / rating) | 1 x 5T x 120mt steel wire x 26mm dia. |
Towing hook | MAMPAEY 60 T | Deck equipment |
Towing Pins (type and number) | 2 |
Shark Jaws - (type and number) | 1 |
Crane | EFFER 20000-3S - 1,5 T knukle boom telescopic | Cargo discharge capacity |
Fuel Oil | 15 cbm/hr at 60mt head |
Fresh Water | 40 cbm/hr at 35mt head | Speed/Consumption |
Max Speed/Consumption | 14 knots at 18 t/day |
Economical Speed/Consumption | 7,5 knots at 6 t/day | Accomodation |
Crew | 14 people | Fi-fi |
FiFi | FiFi1 |
Number of monitors | 2 x 1.200 cbm/hr each - 12,5 bar |
Number of pumps | 2 x 1.400 cbm/hr each |
Foamite | 11,40 cbm | Anti pollution equipment |
Dispersant | 4,30 cbm |
Spray booms | 2 |
Oil Recovery capacity | 24,40 cbm | Rescue equipment |
Rescue Zone | No |
Rescue Boat | Eurovinil OC 360 RH - 25 HP |
Inflatable life rafts | 3 - 48 persons in total |
Life jackets | 16 + 2 (children) |
Fast rescue boat | No | Navigation and communication equipment |
Radar (number and type) | Sperry Decca BridgeMaster |
Inmarsat | 2 Thrane&Thrane Inmarsat C + FBB JRC JUE500 |
VHF | 2 x Thrane&Thrane RT 2048 + 2 x Thrane&Thrane VHF/DSC RM 2042 |
Echo sounder | Tokyo Marine 3FV-4S |
Gyroscopic compass | Cassens&Plath 4914 |
Automation | Cassens&Plath Navipilot V |
