| General info | |
|---|---|
| Year | 1999 |
| Flag | Italian |
| Builder | Orskov - Frederikshaven - Denmark |
| Design | UT 755 |
| Class society | RINA |
| Class notation | +100 A 1.1, Nav. IL, Ap(pl), DCS, +IAQ-1, DYNAPOS AM |
| IMO number | 9183192 | Main particulars |
| Length OA | 67,00 mt |
| DWT | 3.050 T |
| Length BPP | 61,80 mt |
| Breadth moulded | 16,00 mt |
| Depth moulded | 7,00 mt |
| Gross tonnage | 1.996 T |
| Net tonnage | 598 T |
| Maximum draft | 5,87 mt | Cargo capacities |
| Working Clear Deck - space | 620 sqm |
| Working Clear Deck - length x breadth | 46mt x 13,50 mt |
| Max Deck Cargo | 1.500 - T |
| Deck loading | 5 T/sqm |
| Fuel Oil | 867 cbm |
| Fresh Water | multipurpose - 821 cbm |
| Drill Water | multipurpose - 1.335 cbm |
| Brine | multipurpose - 398 - cbm |
| Mud | multipurpose - 772 cbm |
| Base Oil | 208 cbm |
| Dry Bulk | 255 cbm |
| Number of Dry Bulk tanks | 4 | Machinery/Propulsion |
| Main Engines | 2 x Ulstein Bergen KRMB-9 - 2.700 BHP each |
| Drive type (Direct/Diesel Electric) | Direct |
| Total power (BHP) | 5.400 |
| Rudders | 2 x Ulstein Hight Lift Spade |
| Bow thruster(s) (number and BHP) | 2 x Ulstein propeller 150 TV 700 HP - eletric driven |
| Stern thruster(s) (number and BHP) | 1 x Ulstein propeller 150 TV 800 HP - eletric driven |
| Shaft generator | 2 x Stamford HC7-2GH - 1280 kW each - 1800 rpm |
| Diesel generator | 2 x Volvo Penta TAMS122A - 310 kVA each |
| Emergency generator | 1 x Volvo Penta TAMD71B - 160 kVA |
| Fuel type - (MGO / IFO / HFO) | MGO | Anchor handling capacities |
| - | - | Deck equipment |
| Crane | 1 x electro/hydr. 3T SWL with 16mt radius |
| Capstan | 2 x hydraulic Capstans 8T pull |
| Tuggers | 2 x hydraulic Tuggers 10T pull | Cargo discharge capacity |
| Fuel Oil | 200 cbm/hr at 9 bar |
| Fresh Water | 200 cbm/hr at 9 bar |
| Drill Water | 150 cbm/hr at 9 bar |
| Brine | 75 cbm/hr at 18 bar |
| Mud | 2 x 75 cbm/hr at 18 bar |
| Base Oil | 90 cbm/hr at 9 bar |
| Dry bulk | 2 x compressors 23 cbm/hr at 5,6 bar | Speed/Consumption |
| Max Speed/Consumption | 12,5 knots per 19 t/day |
| Economical Speed/Consumption | 9 knots per 8 t/day |
| Port Consumption | 0,5 t/day | Accomodation |
| - | - | Fi-fi |
| FiFi | portable Fi-Fi equipment on deck |
| Number of pumps | 2 x 1.200 cbm/hr at 12 bar | Anti pollution equipment |
| - | - | Rescue equipment |
| Rescue Boat | 1 x 6 persons - 5mt MIDGET rigid rescue boat - 25 HP |
| Inflatable life rafts | 6 - 150 persons in total |
| Life jackets | 43 | Navigation and communication equipment |
| Joystick (Yes / No) | Yes |
| DP | Class1 |
| DP type | Kongsberg K-POS DP-11 |
| Radar (number and type) | 2 x Furuno - S band and X band |
| GMDSS | A1+A2+A3 |
| Inmarsat | 2 x Thrane&Thrane DT4646E + 1 x JRC JUE 500 |
| VHF | Skanti VHF9110 + 3 Thrane&Thrane VHF + 2 Thrane&Thrane VHF/DSC |
| DGPS/GPS | Kongsberg DGPS465 + GPS Furuno GP-80 |
| Echo sounder | Furuno FE-680 |
| Speed log | Sperry SRD 33.1 |
| Radio Telex | Thrane&Thrane RM2151 |
| Gyroscopic compass | Sperry GC-237 |
| Automation | Sperry ADG 3000 VT |
